Migrate for Compute Engine enables you to migrate (Lift and Shift) your virtual machines (VMs), with minor automatic modifications, from your source environment to Google Compute Engine. Migrate for Compute Engine uses data replication technology which continuously replicates disk data from the source VMs to Google Cloud without causing any downtime on the source. You then create VM clones from replicated data for testing and perform predictable VM cut-over to your final workloads running on Google Cloud.
Data replication allows Migrate for Compute Engine to perform an initial replication of the data from the source VM so that you can quickly clone and test a migrated VM. However, because the source VM continues to run during the migration process, including during testing, Migrate for Compute Engine continues to replicate data until you perform the final cut over to your migrated VM.
Migrate for Compute Engine is fully integrated into the Google Cloud console, which means you can perform all migration tasks within the Google Cloud Console UI.
About the migration process
Migrate for Compute Engine provides a simple path for you to migrate your VMs to Compute Engine. The migration process occurs in the following distinct phases:
- Onboard: Select a source VM that you want to migrate.
- Replication: Replicate data from the source VM to Google Cloud. Data replication is a continuous process that takes place in the background until the final cut over or you delete the migration.
- Set VM target details: Configure Compute Engine settings for the migrated VM, such as the project, instance type, memory, network, and more.
- Test-clone: Optionally create a Compute Engine clone of the source VM from the replication data and test it on Google Cloud.
- Cut over: Migrate the source VM to Compute Engine. This process includes stopping the source VM, completing a final replication, and creating the production Compute Engine instance from the source VM.
- Finalize: Perform any final cleanup after a successful migration.
The following image shows these phases:
Each of these phases is described below in more detail.
The first phase of migration is the onboarding phase where you select the VMs to migrate:
For example, for a vSphere data center, the Google Cloud Console shows you all VMs in the data center. Select only the VMs that you want to migrate to onboard the VMs.
After onboarding a VM, start replication of disk data from the source VM to Google Cloud. The source VM continues to run during replication:
Data replication is a continuous process that takes place in the background with minimal impact on the source VM.
Data replication is comprised of two steps:
- First replication step: Migrate for Compute Engine creates the initial VMware snapshot of the source VM data disks and replicates the snapshot data to Google Cloud. Depending on the amount of disk data on the source VM, the first replication can take minutes or hours to complete.
- Incremental replication step: Following a successful first replication step, incremental replication steps occur at set time intervals (every two hours by default). In each step, a new snapshot is created for each data disk. Only data updates that occurred after the previous step are replicated to Google Cloud using the Change Block Tracking (CBT) mechanism.
Once you start replicating the source VM, replication continues until you delete the migration.
At any time, you can pause replication for a VM. For example, you might pause replication on one or more VMs to minimize network resources or to set a higher priority to those migrating VMs which are not paused. You can then resume replication at a later time.
To function properly on Google Cloud, migrated VMs might need changes to their configuration. This process is called OS adaptation. The OS adaptation process is performed at the completion of each replication step to prepare the VM to run in Google Cloud.
For example, Migrate for Compute Engine adapts network configurations, deploys the Compute Engine agent, and enables the serial console on the migrated VM. See OS adaptations for more, including the specific adaptations applied to Linux and Windows VMs.
Set target details
After you initiate data replication, set the Compute Engine target environment on Google Cloud for the migrated VM:
The Compute Engine target details define the landing zone for a migrated VM on Google Cloud. These details include the project, instance type, network setting, and more. Migrate for Compute Engine then creates the Compute Engine instance to host the migrated VM using the target details.
You can modify the target details at any time. When instantiating a Compute Engine instance for either the test-clone or cut-over phase, Migrate for Compute Engine uses the target details settings at the time of the operation.
At any time after the initial replication step of the disk data from the source VM completes, you can clone the source VM to a Compute Engine instance for testing:
While not required, creating a test clone of the VM before deploying to production is highly recommended. Testing is a critical phase of the migration process to ensure that your migrated VM functions correctly in Google Cloud.
If you decide to create a test clone from the source VM, Migrate for Compute Engine creates a Compute Engine instance from the latest replication data using the target details.
Note: The source VM continues to run during the testing phase, which means data replication also continues.
Because the source VM continues to run during the testing phase, you have to ensure that you perform your testing in a sandbox environment that isolates the testing VM from the original source VM.
Once the test VM is up and running, you can verify that the test VM is working as expected and document any changes required to allow the VM to function in Google Cloud. When testing completes, you typically delete the testing Compute Engine instance and create a production Compute Engine instance as part of the cut over phase.
In the cut-over phase, the source VM is stopped, replication is finalized, and a new VM instance is created on Compute Engine on Google Cloud:
You should only perform the cut-over after you have performed all validations during the recommended testing phase.
The cut-over phase includes a short VM downtime and should take place during a scheduled maintenance window. You must first determine the maintenance window during which you can stop the source VM and redirect traffic to the migrated VM running on Compute Engine.
Initiating a cut-over on a migrating VM starts the following sequence of actions performed by Migrate for Compute Engine:
- Shutdown the source VM.
- Perform the final data replication. Because replication occurs throughout all migration phases, the amount of data to replicate should not be very large. If a replication is currently in progress, then it is completed. If no replication is currently in progress, then perform a final replication.
- Stop replication.
- Create the Compute Engine instance from the final replicated data.
After cut over, perform your final validations on the migrated VM. The cut-over results determine your next actions:
- Cut-over failed: For some reason, cutover to the new VM instance on Compute Engine failed, possibly due to a network issue or other simple issue. At this point, the source VM is stopped, and the final replication data is still valid. Retry cut-over to see if the retry clears up the error.
- Cut-over succeeded but the new VM instance is not functioning correctly: If the new VM instance on Compute Engine is not functioning correctly, delete the Compute Engine VM, and start the source VM. This process is called “rollback”.Because of the complexity of rolling back a migration, roll back is not an automated process. If you have to perform a rollback, you have to ensure that you redirect traffic back to the source VM. Also, note any data written on the Compute Engine instance is not pushed back to the original source VM.With the source VM functioning again, you can diagnose and resolve the migration error. After the error has been resolved, you can restart replication and then retry the migration.
- Cut over succeeded, and the new VM instance is working correctly: If your validation results determine that the new VM is working correctly, your migration is complete.
Following a successful cut-over, you finalize the migration. Performing finalize deletes all replication data and all other storage resources associated with the migrated VM, and changes the state of the VM to Finalized.
Finalize can be performed only on VMs in the Cut-Over state:
The replication data used to create the Compute Engine VM is retained after cut over. That means you can use that data to create additional instances of your migrated VM after cut over. However, you eventually want to free up the storage in the finalize phase.
